Generally that’s fine and I agree, but one edge case that people overlook that I think is worth mentioning (and maybe what gp heard about and is trying to articulate) is that having an inverter or generator on the same circuit as a big energy consumer means that the breaker wouldn’t see the total energy being used by the consumer, and so it might not trip even if the consumer pulls too much wattage. That’s the main reason I know of why power sources should be on their own breaker - so it doesn’t hide power from the breaker but forces it to go out the generator circuit breaker and back in the consumer breaker so it can be protected properly.










I think the warning you might be thinking of is that a breaker can fail to pop if an inverter/generator is on the same circuit as a high wattage device. Since some energy would go directly from generation to device, the breaker will only see the “net” energy consumption. So if the generator puts out 1500W and the device decides to draw 3000W, a 15A breaker only sees 1500, and won’t trip even though the device is pulling way too much. If the breaker was sized for the wiring, then the wiring to that outlet could catch fire due to the breaker not tripping. That’s the main reason I know of why a generator or inverter should be on a dedicated circuit, to force the energy out one breaker and in another, so that the breaker can see an accurate measure of energy and trip when necessary.
